- Intel Core i7-13700, 16C (8P + 8E)/24T, Max Turbo up to 5.2GHz, P-core 2.1/5.1GHz, E-core 1.5/4.1GHz, 30MB
- 1x 16GB UDIMM DDR5-4800 Non-ECC
- 1x 512GB SSD M.2 2280 PCIe 4.0x4 Performance NVMe Opal
- Intel UHD Graphics 770
- 1x NVIDIA T1000 8GB
- Windows 11 Pro
The leader in entry-level workstations
- The compute muscle of a workstation for the price of a desktop
- Powered by 13th Gen Intel® Core™ processors
- Choice of professional NVIDIA discrete graphics cards
- Advanced thermal design for extra power and performance
- Reliable, easy-to-deploy, & versatile, supports up to 12 displays
- ISV-certified, perfect for designers, engineers, & students
| Processor |
|---|
| Processor manufacturer |
Intel |
| Processor family |
Intel® Core™ i7 |
| Processor generation |
13th gen Intel® Core™ i7 |
| Processor model |
i7-13700 |
| Processor cores |
16 |
| Processor threads |
24 |
| Processor boost frequency |
5.2 GHz |
| Performance cores |
8 |
| Efficient cores |
8 |
| Performance-core Max Turbo Frequency |
5.1 GHz |
| Efficient-core Max Turbo Frequency |
4.1 GHz |
| Performance-core base frequency |
2.1 GHz |
| Efficient-core base frequency |
1.5 GHz |
| Processor cache |
30 MB |
| Processor cache type |
Smart Cache |
| Number of processors installed |
1 |
| Maximum turbo power |
219 W |
| Processor base power |
65 W |
| Memory |
|---|
| Internal memory |
16 GB |
| Maximum internal memory |
128 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory layout (slots x size) |
1 x 16 GB |
| Memory slots |
4x DIMM |
| Memory clock speed |
4800 MHz |
| Storage |
|---|
| Total storage capacity |
512 GB |
| Optical drive type |
No |
| Storage media |
SSD |
| Total SSDs capacity |
512 GB |
| Number of SSDs installed |
1 |
| SSD capacity |
512 GB |
| NVMe |
Yes |
| SSD interface |
PCI Express 4.0 |
| SSD form factor |
M.2 |
| Card reader integrated |
Yes |
| Compatible memory cards |
SD |
| Graphics |
|---|
| Discrete graphics card |
Yes |
| On-board graphics card |
Yes |
| Discrete GPU manufacturer |
NVIDIA |
| Discrete graphics card model |
NVIDIA T1000 |
| Discrete graphics card memory |
8 GB |
| Number of discrete graphics cards |
1 |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel® UHD Graphics |
| On-board graphics card model |
Intel UHD Graphics 770 |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wi-Fi |
No |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| Microphone in |
Yes |
| Line-out |
Yes |
| Combo headphone/mic port |
Yes |
| Design |
|---|
| Chassis type |
Tower |
| Colour name |
Black |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Product colour |
Black |
| Performance |
|---|
| Product type |
Workstation |
| Motherboard chipset |
Intel W680 |
| Audio chip |
Realtek ALC897Q-CG |
| Audio system |
High Definition Audio |
| Trusted Platform Module (TPM) |
Yes |
| Software |
|---|
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Power |
|---|
| Power supply |
500 W |
| Power supply input voltage |
100 - 240 V |
| Power supply input frequency |
50 - 60 Hz |
| Certificates |
|---|
| Compliance certificates |
RoHS |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR, TCO, EPEAT Gold |
| Weight & dimensions |
|---|
| Width |
180 mm |
| Depth |
370 mm |
| Height |
415 mm |
| Weight |
13.6 kg |
| Packaging content |
|---|
| Display included |
No |
| Mouse included |
Yes |
| Keyboard included |
Yes |
| General |
|---|
| Product series |
P |
| Product family |
ThinkStation |
