- Large Enterprise Business
- Rack (2U)
- SSD Storage drives installed 23 TB
Looking for simple, high-performance, and low-cost shared storage that delivers application acceleration across all your server workloads? HPE MSA Storage has been the leading shared storage solution for HPE ProLiant servers for almost three decades. With over 600,000 storage arrays sold, MSA continues to deliver on its promise of simple, fast, and affordable storage for SMB customers. The HPE MSA Gen7 Storage array sets a new standard for entry-level shared storage by providing an affordable path to high-performance storage without compromising on the simplicity and reliability that its customers depend on. The MSA Gen7 array portfolio delivers up to 2x more system performance while supporting user scalability beyond 7 PB per array with new high-capacity media options. New Gen7 innovations supporting online system and media firmware updates, as well as simpler and faster access to the HPE MSA Health Check tool, reduce the complexity and time required for routine system maintenance.
What is new supporting point:
All MSA Gen6 and Gen7 storage array models are now fully certified for use with HPE Morpheus VM Essentials Software.
MSA HDD and SSD media options supporting an increase in MSA Gen7 raw capacity of up to a maximum of 7.37 PB.
Customer configurable HPE MSA Gen7 storage array models and storage media options available through the HPE Smart Choice program.
HPE Smart Choice MSA Gen7 all-flash storage array bundles with up to 92 TB of raw storage capacity included, supporting 16/32 Gb Fibre Channel, 10/25 GbE iSCSI, and 12 Gb SAS host connectivity.
| Storage |
|---|
| Storage drives installed |
Yes |
| Installed storage drive type |
SSD |
| Number of storage drives installed |
12 |
| Total installed storage capacity |
23 TB |
| Supported storage drive types |
HDD & SSD |
| Number of storage drives supported |
24 |
| Maximum supported storage capacity |
2710 TB |
| Storage drive capacity |
1.92 TB |
| Storage drive size |
2.5" |
| Supported storage drive interfaces |
SAS |
| RAID levels |
0, 6, 1, 5, 10 |
| Self-Encrypting Drive (SED) |
No |
| Storage drive type |
Twelve 1.92 TB Read Intensive SSDs included; Add up to twelve additional SFF HDD and/or SSD per base array |
| Ports & interfaces |
|---|
| Fibre Channel |
Yes |
| Design |
|---|
| Device class |
Large Enterprise Business |
| Chassis type |
Rack (2U) |
| System requirements |
|---|
| Linux operating systems supported |
Yes |
| Server operating systems supported |
Yes |
| Weight & dimensions |
|---|
| Width |
445 mm |
| Depth |
508 mm |
| Height |
89 mm |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
0 - 85% |
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
0 - 90% |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR |
| Other features |
|---|
| Form factor |
SFF |
| Compatible operating systems |
Windows Server; VMware vSphere™; Red Hat Linux; SUSE™ SLES; See HPE SPOCK for more details. |
| Expansion description |
2U 24-drive SFF drive enclosure and/or 2U 12-drive LFF drive enclosure (add up to 9 in any combination) |
| Storage drive controller |
2x 32 Gb Fibre Channel 4-port Controller |
