DrayTek VigorAP 805 Mesh AX3000 Wireless Access Point, 2.5GbE Uplink, additional 1GbE for Wired Connectivity, Cylinder Form-factor

Draytek
€117.99
€117.99
Tax included.
Out of Stock
  • Wi-Fi 6 Mesh Wireless Access Point
  • AX3000 – 11ax Dual Band Wireless
  • WPA3 Security – Stronger Security with WPA3 Personal & Enterprise
  • Power through DC Power Adapter (included)
  • Multi-SSID over Mesh – Separate Internal and Guest Networks over Mesh*
  • 2.5Gb Ethernet Uplink & Additional GbE interface
  • Centrally Managed or Standalone Operation
  • Root AP for AP Management

The VigorAP 805 is a high-performance Mesh Wireless Access Point. It offers up to 3Gbps dual-band wireless performance and up to 2.5Gb Ethernet connectivity. The second Gigabit Ethernet port can be used as a mini switch to connect a computer or printer.

Features
2.4 GHz Yes
6 GHz No
5 GHz Yes
Maximum data transfer rate 3000 Mbit/s
Maximum data transfer rate (2.4 GHz) 2400 Mbit/s
Maximum data transfer rate (5 GHz) 600 Mbit/s
Ethernet LAN data rates 10,100,1000,2500 Mbit/s
Number of simultaneously connected devices (max) 256
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v
Number of users 256 user(s)
Automatic channel selection Yes
Full duplex Yes
MIMO Yes
Spatial streams 2
MIMO type Multi User MIMO
Spread spectrum method OFDMA
Fit AP mode features 802.11k & 802.11v smart roaming, Mesh networking, WDS zero-configuration deployment, Wireless distribution system (WDS)
Wi-Fi roaming Yes
Fast roaming Yes
VLAN support Yes
Wireless isolation Yes
Smart mesh system Yes
Band steering Yes
Airtime Fairness (ATF) Yes
Dynamic Frequency Selection (DFS) Yes
Quality of Service (QoS) support No
Cloud services supported Draytek VigorACS
BeamForming Yes
Security
Security algorithms SNMP, SNMPv2, SNMPv3, SSH, SSID, WPA, WPA2, WPA2-Enterprise, WPA2-Personal, WPA3, WPA3-Enterprise, WPS
MAC address filtering Yes
Service Set Identifier (SSID) features Hidden SSID, Multiple SSIDs, SSID broadcast, SSID broadcast on/off
Number of SSID supported 16
Auto Wireless Distribution System (WDS) Yes
Access Control List (ACL) Yes
Protocols
DHCP server Yes
DHCP client Yes
Management protocols TR-069
IPv4 & IPv6 features Dual stack IPv4/IPv6
Management features
Web-based management Yes
Local AP management Telnet
Command-line interface (CLI) Yes
Syslog Yes
Management platform Draytek vigorACS
Batch upgrade Yes
Firmware upgradeable Yes
Ports & interfaces
Interface 2
Ethernet LAN (RJ-45) ports 2
DC-in jack Yes
Power
Power over Ethernet (PoE) No
Power consumption (max) 12 W
Design
Placement Desk, Table, Shelf
Product colour White
Housing material Plastic
Reset button Yes
LED indicators LAN, System
Antenna
Antenna type Internal
Antenna direction type Omni-directional
Antennas quantity 5
Antenna gain level (max) 4.9 dBi
Performance
Operating system installed DrayOS
Certificates
PSTI certified Yes
Compliance certificates CE, UKCA
Weight & dimensions
Width 110 mm
Depth 110 mm
Height 153 mm
Weight 405 g
Packaging content
Quantity per pack 1 pc(s)
AC adapter included Yes
Cables included LAN (RJ-45)
Quick start guide Yes
Other features
Rack mounting No
Operational conditions
Operating relative humidity (H-H) 10 - 90%
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 60 °C
