- VDSL2 or 2.5Gb Ethernet Router with Failover
- Integrated VoIP gateway with dual FXS phone ports
- 1x 2.5 Gigabit RJ-45 switchable WAN/LAN Port
- 3x Gigabit RJ-45 LAN Ports
- In total 4 (3+1) LAN ports (1 is the WAN/LAN switchable)
- Up to 2.3Gbps Firewall Throughput
- Up to 300Mbps IPsec VPN Throughput
- 16x LAN-to-LAN & Remote Teleworker VPN Tunnels
- AX3000 – Wi-Fi 6 Dual Band Wireless (‘ax’ models)
- SPI Firewall and Content Filtering
- Compatible with VigorACS central management platform
High-Performance VDSL, Wi-Fi 6 and VoIP Connectivity for SMEs
The DrayTek Vigor 2767Vax combines high-speed VDSL and full fibre connectivity, AX3000 Wi-Fi 6 wireless, integrated VoIP telephony and advanced business networking features in a single device. Designed for home offices, small businesses and distributed teams, it delivers secure internet access, business-grade VPN connectivity, integrated SIP telephony through two FXS ports, and up to 2.3Gbps firewall throughput for modern communications and cloud-based applications.
| WAN connection |
|---|
| Ethernet WAN |
Yes |
| DSL WAN |
Yes |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
Yes |
| WAN connection type |
RJ-11, RJ-45, USB |
| Wireless LAN features |
|---|
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) |
3000 Mbit/s |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| Cabling technology |
10/100/1000/2500Base-T |
| Full duplex |
Yes |
| Flow control support |
Yes |
| Multicast support |
Yes |
| Port triggering |
Yes |
| Port forwarding |
Yes |
| Load balancing system |
Yes |
| Dynamic DNS (DDNS) |
Yes |
| Policy-based routing |
Yes |
| SSID-based VLAN assignment |
Yes |
| Static route |
Yes |
| Number of guest networks (5 GHz) |
8 |
| Number of guest networks (2.4 GHz) |
8 |
| Wireless Distribution System (WDS) bridge |
Yes |
| VPN tunnels quantity |
16 |
| Internet connection backup |
Yes |
| VPN Passthrough |
Yes |
| VPN support |
IPsec IKEv1, IKEv2, IKEv2 EAP
IPsec-XAuth
OpenVPN
WireGuard
EasyVPN - New! |
| DSL features |
|---|
| ADSL2+ |
Yes |
| VDSL2 |
Yes |
| Internal modem |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
4 |
| USB port |
Yes |
| USB 2.0 ports quantity |
2 |
| RJ-11 ports quantity |
1 |
| DC-in jack |
Yes |
| Management features |
|---|
| Web-based management |
Yes |
| Web-based setup wizard |
Yes |
| Bandwidth control |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Quality of Service (QoS) support |
Yes |
| Wake-on-LAN ready |
Yes |
| Reset button |
Yes |
| Intelligent Mesh technology |
Yes |
| WPS push button |
Yes |
| MIMO |
Yes |
| MU-MIMO technology |
Yes |
| Security |
|---|
| Security algorithms |
3DES, AES, SSH, HTTPS, IPSec, WPA2-Enterprise, DES, OWE, WPA2-Personal, WEP, WPA3-Enterprise, WPA3-Personal, WPA-Enterprise, WPA-Personal |
| Firewall |
Yes |
| Access Control List (ACL) |
Yes |
| Guest access |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| Schedule access |
Yes |
| DDoS protection |
Yes |
| Parental control |
Yes |
| DoS attack prevention |
Yes |
| Filtering |
Yes |
| MAC address filtering |
Yes |
| IP address filtering |
Yes |
| URL filtering |
Yes |
| System event log |
Yes |
| IGMP snooping |
Yes |
| DMZ support |
Yes |
| Network address translation (NAT) |
Yes |
| Protocols |
|---|
| DHCP client |
Yes |
| DHCP server |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| IPv4 & IPv6 features |
Dual stack IPv4/IPv6 |
| Routing protocols |
BGP, RIPng, RIP-1, OSPF, RIP-2 |
| Design |
|---|
| Product type |
Tabletop router |
| Product colour |
White |
| Housing material |
Plastic |
| Wall mountable |
Yes |
| LED indicators |
DSL, LAN, Power, USB |
| On/off switch |
Yes |
| Packaging content |
|---|
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Antenna included |
Yes |
| Quick start guide |
Yes |
| Antenna |
|---|
| Antenna design |
Internal & external |
| Detachable antenna(s) |
Yes |
| Features |
|---|
| Languages support |
English |
| Operating system installed |
DrayOS 5 |
| Firmware upgradeable |
Yes |
| Power |
|---|
| Power consumption (typical) |
22.1 W |
| External power adapter |
Yes |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-25 - 70 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Weight |
665 g |
| Height |
42 mm |
| Depth |
131 mm |
| Width |
207 mm |
| Logistics data |
|---|
| Warranty period |
2 year(s) |
| Country of origin |
Taiwan |
