- NAS Rack (2U)
- Number of storage drives supported: 12 HDD & SSD
- Intel® Xeon® D D-1541 2.1 GHz
- 8 DDR4
- Ethernet LAN
- Cooling type: Active
- 500 W
Built-in High Availability
Keep file sharing services, block storage, backups, and other office applications online with automatic minute-level failover. Defend against operational disruptions with two independent and hot-swappable controllers operating in an active-passive configuration.
Made for demanding environments
The SA3400D is engineered to provide outstanding performance in both NAS and SAN storage roles. Its throughput and random I/O performance support efficient SMB and NFS file serving as well as a range of iSCSI and Fibre Channel block storage applications.
Consolidate your data infrastructure
Manage, protect, and share data with versatile business solutions. Empower team collaboration, sandbox applications, and provide VM storage on a unified platform.
Flexible options to meet changing needs
Flexibly scale storage capacity, optimize I/O performance, and meet different network needs with a range of expansion options.
Add storage capacity on demand
Scale server capacity up to 576 TB7 when your data storage needs increase by adding two 12-bay RXD1219sas expansion units.
Boost network and I/O performance
Add 10/25GbE connectivity with optional add-in cards.8 Create all-flash storage volumes with SAS SSD for lightening-fast I/O, or boost IOPS and cut down latency on HDD volumes by creating SAS SSD read/write cache volumes.
Performance backed by Synology drives
Engineered to handle intensive workloads, Synology hard drives consistently deliver top-grade performance.
| Storage |
|---|
| Storage drives installed |
No |
| Total installed storage capacity |
0 TB |
| Number of storage drives supported |
12 |
| Installed storage drive type |
No |
| Supported storage drive types |
HDD & SSD |
| Storage drive capacity |
0 GB |
| Storage drive interface |
Serial Attached SCSI (SAS) |
| Storage drive sizes supported |
2.5,3.5" |
| RAID support |
Yes |
| RAID levels |
0, 1, 5, 10, JBOD |
| Hot-swap drive bays |
Yes |
| Supported file systems |
BTRFS, ext4 |
| Processor |
|---|
| Processor manufacturer |
Intel |
| Processor family |
Intel® Xeon® D |
| Processor model |
D-1541 |
| Processor frequency |
2.1 GHz |
| Processor boost frequency |
2.7 GHz |
| Processor cores |
8 |
| Processor cache |
12 MB |
| CPU configuration (max) |
1 |
| Memory |
|---|
| Internal memory |
8 GB |
| Internal memory type |
DDR4 |
| Maximum RAM supported |
64 GB |
| Network |
|---|
| Ethernet LAN |
Yes |
| Supported network protocols |
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
| Link aggregation |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
3 |
| USB port |
No |
| Design |
|---|
| Chassis type |
Rack (2U) |
| Cooling type |
Active |
| Number of fans |
2 fan(s) |
| Fan diameter |
6 cm |
| Performance |
|---|
| Type |
NAS |
| Backup function |
Yes |
| Number of users |
16000 user(s) |
| Reset button |
Yes |
| Access Control List (ACL) |
Yes |
| Power |
|---|
| Power supply unit (PSU) capacity |
500 W |
| Number of power supply units |
2 |
| Redundant power supply (RPS) support |
Yes |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Weight & dimensions |
|---|
| Width |
482 mm |
| Depth |
724 mm |
| Height |
88 mm |
| Weight |
19.7 kg |
| Processor special features |
|---|
| Intel TSX-NI version |
1.00 |
| Intel Secure Key Technology version |
1.00 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 35 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage temperature (T-T) |
-20 - 60 °C |
