- Dual ball bearing design
- 3-pin connector with tachometer wire
- Includes a 3-pin to 4-pin LP4 adapter
Add additional chassis cooling with a 60mm ball bearing fan
This 6x2cm replacement Fan helps keep your PC cool, in turn increasing dependability and extending component lifespan. The fan features an efficient ball-bearing design that provides durable cooling, and offers a Tachometer pin on the TX3 motherboard connector that provides the host system with fan operating status. Ensuring broad compatibility, the 6x2cm fan includes a TX3 to LP4 adapter that lets you power the fan using an LP4 connection to the PSU as opposed to a motherboard TX3 connection. Designed to provide a reliable PC cooling solution, the replacement fan is backed by StarTech.com's 2-year warranty.
| Performance |
|---|
| Suitable location |
Computer case |
| Type |
Fan |
| Fan diameter |
6 cm |
| Rotational speed (max) |
4500 RPM |
| Noise level (high speed) |
28 dB |
| Maximum airflow |
21.46 cfm |
| Operating temperature (T-T) |
-10 - 80 °C |
| Design |
|---|
| Product colour |
Black |
| Material |
Plastic |
| Number of fans |
1 fan(s) |
| Weight & dimensions |
|---|
| Width |
20 mm |
| Depth |
60 mm |
| Height |
60 mm |
| Weight |
38 g |
| Package width |
65 mm |
| Package depth |
115 mm |
| Package height |
35 mm |
| Package weight |
67 g |
| Technical details |
|---|
| Compliance certificates |
RoHS |
| Bearing technology |
Ball bearing |
| Other features |
|---|
| Rotational speed |
4500 RPM |
| Connector(s) |
1 - TX3 Female |
| Dimensions (WxDxH) |
60 x 60 x 20 mm |
| Airflow |
22.1 |
| Logistics data |
|---|
| Harmonized System (HS) code |
84733080 |
| Master (outer) case width |
350 mm |
| Master (outer) case length |
454 mm |
| Master (outer) case height |
292 mm |
| Products per master (outer) case |
200 pc(s) |
