- Entry level High Speed HDMI 2.1 cable for home and small office applications
- Supports UHD resolutions up to 7680x4320@60Hz 4:4:4 10bit
- Robust PVC housing, nickel connectors, gold flashed contacts
- Triple shielded cable, corrosion resistant copper coated steel 28AWG conductors
- Supports 3D, 8K, 48Gbps, HEC, ARC, EARC CEC, Dolby® True HD, DTS-HD Master Audio, Dolby Atmos, DTS:X;
- 10 year warranty
From the lines cable connectivity concept developed by Lindy, Black Line 8K60Hz HDMI cables are fully featured, entry level high resolution connection solutions, perfect for home and small office use.
Black Line 8k60hz or 4K120hz cables feature triple shielded construction with 28AWG copper coated steel conductors for premium performance and corrosion resistance. Nickel connectors and gold flashed contacts maintain signal integrity and reliability.
UHD resolutions up to 7680x4320@60Hz and 3840x2160@120hz are supported. 8K Black Line HDMI cables are also capable of transmitting 32 channel audio and Dolby® Atmos and DTS:X
The 8K Black line HDMI cable supports 48Gbps bandwidth capacity in cable lengths up to 5m.
| Features |
|---|
| Cable length |
5 m |
| Connector 1 |
HDMI Type A (Standard) |
| Connector 2 |
3 x HDMI Type A (Standard) |
| Connector 1 gender |
Male |
| Connector 2 gender |
Male |
| Connector 1 form factor |
Straight |
| Connector 2 form factor |
Straight |
| Product colour |
Black |
| HDMI version |
2.1 |
| Supported graphics resolutions |
7680 x 4320 |
| Dolby technologies |
DTS:X, Dolby Atmos |
| Data transfer rate |
48 Gbit/s |
| Maximum refresh rate |
60 Hz |
| AWG wire size |
30 |
| Connector contacts plating |
Gold |
| Connector material |
Nickel |
| Connector housing material |
Polyvinyl chloride (PVC) |
| Cable material |
Copper-clad steel (CCS) |
| Cable type |
Round cable |
| Cable jacket material |
Polyvinyl chloride (PVC) |
| Shield material |
Aluminium |
| Bend radius (min) |
7 cm |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-10 - 80 °C |
| Storage temperature (T-T) |
-20 - 85 °C |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Certificates |
|---|
| Compliance certificates |
REACH, RoHS |
| Weight & dimensions |
|---|
| Cable diameter |
6 mm |
| Packaging data |
|---|
| Package width |
20 mm |
| Package depth |
34.2 mm |
| Package height |
10.9 mm |
| Package type |
Polybag |
| Quantity per pack |
1 pc(s) |
| Logistics data |
|---|
| Warranty period |
10 year(s) |
| Quantity per box |
1 pc(s) |
