- Workstation Black 1000 W
- AMD Ryzen Threadripper PRO 5955WX 4 GHz Processor cores: 16
- 32 GB DDR4-SDRAM 3200 MHz
- 1 TB SSD Card reader integrated
- Ethernet LAN 100,1000,2500,10000 Mbit/s
- Windows 11 Pro 64-bit
GAME CHANGING POWER, RELIABILITY, AND SPEED
The ThinkStation P620 is the only AMD Ryzen Threadripper PRO powered workstation, delivering
game-changing power and speed with the largest core count professional workstation: up to 64 cores and 4.5GHz. Perfect for those who demand more power for multi-threaded applications, the P620 combines Lenovo’s legendary reliability, experience and customerdriven innovation with professional manageability and enterprise-class support. Purpose built with the speed and configurability you
crave, this powerhouse workstation offers PCIe Gen4 for increased storage speed and expandable memory, as well as unmatched NVIDIA® graphics support, and 10GB of built-in ethernet—a new standard in connectivity.
| Processor |
|---|
| Processor manufacturer |
AMD |
| Processor family |
AMD Ryzen Threadripper PRO |
| Processor generation |
AMD Ryzen Threadripper PRO 5000 WX-Series |
| Processor model |
5955WX |
| Processor cores |
16 |
| Processor frequency |
4 GHz |
| Performance-core base frequency |
4.5 GHz |
| Processor cache |
64 MB |
| Processor cache type |
L2 & L3 |
| Number of processors installed |
1 |
| Memory |
|---|
| Internal memory |
32 GB |
| Maximum internal memory |
1 TB |
| Internal memory type |
DDR4-SDRAM |
| Memory slots |
8x DIMM |
| Memory clock speed |
3200 MHz |
| Memory channels |
Octa-channel |
| Non-ECC |
No |
| ECC |
Yes |
| Storage |
|---|
| Total storage capacity |
1 TB |
| Optical drive type |
No |
| Storage media |
SSD |
| Total SSDs capacity |
1 TB |
| Number of SSDs installed |
1 |
| SSD capacity |
1 TB |
| NVMe |
Yes |
| SSD interface |
PCI Express 4.0 |
| SSD form factor |
M.2 |
| Card reader integrated |
Yes |
| Graphics |
|---|
| Discrete graphics card |
No |
| On-board graphics card |
No |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Not available |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
100,1000,2500,10000 Mbit/s |
| LAN controller |
Marvell AQtion AQN-107 |
| Wi-Fi |
No |
| Bluetooth |
No |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
2 |
| PS/2 ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| Microphone in |
Yes |
| Headphone outputs |
1 |
| Line-in |
Yes |
| Line-out |
Yes |
| Combo headphone/mic port |
Yes |
| Expansion slots |
|---|
| PCI Express x8 (Gen 4.x) slots |
2 |
| PCI Express x16 (Gen 4.x) slots |
4 |
| Design |
|---|
| Chassis type |
Tower |
| Volume |
33 L |
| Placement supported |
Vertical |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Product colour |
Black |
| Performance |
|---|
| Product type |
Workstation |
| Motherboard chipset |
AMD WRX80 |
| Audio chip |
Realtek ALC4050H |
| Audio system |
High Definition Audio |
| Built-in speaker(s) |
No |
| Password protection |
Yes |
| Password protection type |
Power on, Supervisor |
| Trusted Platform Module (TPM) |
Yes |
| Software |
|---|
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Windows 11 free upgrade |
No |
| Operating system language |
English |
| Power |
|---|
| Power supply |
1000 W |
| 80 PLUS certification |
80 PLUS Platinum |
| Operational conditions |
|---|
| Operating temperature (T-T) |
10 - 35 °C |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Operating altitude |
0 - 3048 m |
| Non-operating altitude |
0 - 12192 m |
| Certificates |
|---|
| Compliance certificates |
RoHS |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR, EPEAT Silver, GREENGUARD |
| Sustainability compliance |
Yes |
| Weight & dimensions |
|---|
| Width |
165 mm |
| Depth |
455 mm |
| Height |
446 mm |
| Weight |
24 kg |
| Packaging content |
|---|
| Display included |
No |
| Mouse connectivity |
Wired |
| Mouse included |
Yes |
| Keyboard connectivity |
Wired |
| Keyboard included |
Yes |
| General |
|---|
| Product series |
P |
| Product family |
ThinkStation |
