Work fast with our most powerful entry workstation Experience server-grade power in a desktop with impressive expandability. Cut through complex BIM, rendering and visualization projects with high-performance graphics and Intel® processers.
Processor
Processor manufacturer
Intel
Processor family
Intel® Core™ i7
Processor generation
8th gen Intel® Core™ i7
Processor model
i7-8700
Processor cores
6
Processor threads
12
Processor boost frequency
4.6 GHz
Processor frequency
3.2 GHz
Processor socket
LGA 1151 (Socket H4)
Processor cache
12 MB
Processor cache type
L3
System bus rate
8 GT/s
Bus type
DMI3
Processor series
Intel Core i7-8700 Desktop Series
Processor operating modes
64-bit
Processor lithography
14 nm
Thermal Design Power (TDP)
65 W
Processor codename
Coffee Lake
Tjunction
100 °C
PCI Express configurations
1x16, 1x8+2x4, 2x8
Maximum number of PCI Express lanes
16
PCI Express slots version
3.0
Number of processors installed
1
Maximum internal memory supported by processor
64 GB
Memory types supported by processor
DDR4-SDRAM
Memory clock speeds supported by processor
2666 MHz
Memory bandwidth supported by processor (max)
41.6 GB/s
Memory
Internal memory
16 GB
Internal memory type
DDR4-SDRAM
Memory layout (slots x size)
1 x 16 GB
Memory slots
4x DIMM
Memory clock speed
2666 MHz
ECC
No
Storage
Total storage capacity
1 TB
Optical drive type
No
Storage media
HDD
Number of storage drives installed
1
Total HDDs capacity
1 TB
Number of HDDs installed
1
HDD capacity
1 TB
HDD interface
SATA
HDD speed
7200 RPM
Card reader integrated
No
Intel® Optane™ Memory module installed
Yes
Intel® Optane™ Memory module capacity
16 GB
Graphics
Discrete graphics card
No
On-board graphics card
Yes
Discrete graphics card model
Not available
On-board graphics card family
Intel® UHD Graphics
On-board graphics card model
Intel® UHD Graphics 630
Number of displays supported (on-board graphics)
3
Maximum on-board graphics card memory
64 GB
On-board graphics card dynamic frequency (max)
1200 MHz
On-board graphics card base frequency
350 MHz
On-board graphics card ID
0x3E92
On-board graphics card OpenGL version
4.5
On-board graphics card DirectX version
12.0
Number of execution units
24
Network
Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Wi-Fi
No
Ports & interfaces
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
6
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
DVI port
No
DisplayPorts quantity
2
DisplayPort version
1.2
Ethernet LAN (RJ-45) ports
1
Microphone in
No
Headphone outputs
1
Line-in
Yes
Line-out
Yes
Combo headphone/mic port
Yes
Expansion slots
PCI Express x1 (Gen 3.x) slots
2
PCI Express x4 (Gen 3.x) slots
2
PCI Express x16 (Gen 3.x) slots
1
Design
Chassis type
Tower
Placement supported
Vertical
Number of 3.5" bays
2
Number of 5.25" bays
2
Product colour
Black
Country of origin
China
Performance
Product type
Workstation
Market positioning
Business
Motherboard chipset
Intel C246
Audio chip
Conexant CX20632-31Z
Software
Operating system installed
Windows 10 Pro
Operating system architecture
64-bit
Processor special features
Processor code
SR3QS
Intel® Optane™ Memory Ready
Yes
Processor ARK ID
126686
Thermal solution specification
PCG 2015C
Scalability
1S
Supported instruction sets
AVX 2.0, SSE4.1, SSE4.2
Processor package size
37.5 x 37.5 mm
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Yes
Intel® OS Guard
Yes
Intel® Secure Key
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Thermal Monitoring Technologies
Yes
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® InTru™ 3D Technology
Yes
Intel TSX-NI version
1.00
Intel Secure Key Technology version
1.00
Intel Stable Image Platform Program (SIPP) version
1.00
Intel Identity Protection Technology version
1.00
Intel Enhanced Halt State
Yes
Intel Clear Video Technology
Yes
Intel Software Guard Extensions (Intel SGX)
Yes
Intel TSX-NI
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
HP BIOSphere Gen4; HP Business PC Security Lock Kit; HP Client Security Suite Gen 4; HP Keyed Cable Lock Kit; HP Solenoid Hood Lock + Sensor; HP Sure Click; HP Sure Run; HP Sure Start Gen 4; HP UltraSlim Cable Lock Kit
