- Windows 11 Home 64-bit
- AMD Ryzen 7 260 (3.8GHz)
- 16" WUXGA 1920 x 1200 IPS-Level, NVIDIA GeForce RTX 5060 (8GB GDDR7)
- 16GB (5600MHz) DDR5-SDRAM & 512GB SSD
Serious Gaming Specs
As a member of the TUF Gaming family, the A16 boasts some seriously impressive specs, giving you access to the very best of gaming on Windows 11. Featuring AMD Ryzen™ 9 8940HX processor and an NVIDIA® GeForce RTX™ 5070 Laptop GPU, the A16 can easily play the latest games or keep your workflow on schedule. Paired with 16GB of DDR5 5600MHz memory per slot and dual expandable PCIe Gen 4 storage slots, this little machine is ready for anything, right out of the box.
| Design |
|---|
| Product type |
Laptop |
| Product colour |
Black, Grey |
| Colour name |
Jaeger Gray |
| Form factor |
Clamshell |
| Display back cover material |
Plastic |
| Housing material |
Aluminium, Plastic |
| Market positioning |
Gaming |
| Certified refurbished |
No |
| Display |
|---|
| Display diagonal |
40.6 cm (16") |
| Display resolution |
1920 x 1200 pixels |
| Touchscreen |
No |
| HD type |
WUXGA |
| Panel type |
IPS-Level |
| Native aspect ratio |
16:10 |
| Anti-glare screen |
Yes |
| Display brightness |
300 cd/m² |
| Colour gamut |
100% |
| RGB colour space |
sRGB |
| Display response rise/fall |
3 ms |
| Maximum refresh rate |
144 Hz |
| Contrast ratio (typical) |
1000:1 |
| Processor |
|---|
| Processor manufacturer |
AMD |
| Processor family |
AMD Ryzen™ 7 |
| Processor generation |
AMD Ryzen 200 Series |
| Processor model |
260 |
| Processor cores |
8 |
| Processor threads |
16 |
| Processor boost frequency |
5.1 GHz |
| Processor frequency |
3.8 GHz |
| L3 cache |
16 MB |
| L2 cache |
8 MB |
| Processor cache type |
L2 & L3 |
| Neural processor unit (NPU) |
|---|
| Neural processor unit (NPU) |
AMD Ryzen AI |
| Total processor performance up to |
38 TOPs |
| NPU performance up to |
16 TOPs |
| Memory |
|---|
| Internal memory |
16 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory form factor |
SO-DIMM |
| Memory clock speed |
5600 MHz |
| Memory slots |
2x SO-DIMM |
| Maximum internal memory |
64 GB |
| Storage |
|---|
| Total storage capacity |
512 GB |
| Storage media |
SSD |
| Total SSDs capacity |
512 GB |
| Number of SSDs installed |
1 |
| SSD capacity |
512 GB |
| NVMe |
Yes |
| SSD interface |
PCI Express 4.0 |
| SSD form factor |
M.2 |
| Optical drive type |
No |
| Card reader integrated |
No |
| Graphics |
|---|
| On-board graphics card |
Yes |
| Discrete graphics card |
Yes |
| Discrete GPU manufacturer |
NVIDIA |
| Discrete graphics card model |
NVIDIA GeForce RTX 5060 |
| Discrete graphics card memory |
8 GB |
| Discrete graphics memory type |
GDDR7 |
| On-board GPU manufacturer |
AMD |
| On-board graphics card family |
AMD Radeon |
| On-board graphics card model |
AMD Radeon 780M |
| Total Graphics Power (TGP) |
115 W |
| NVIDIA G-SYNC |
Yes |
| Audio |
|---|
| Audio system |
Dolby Atmos |
| Number of built-in speakers |
2 |
| Built-in microphone |
Yes |
| Camera |
|---|
| Front camera |
Yes |
| Front camera resolution |
1920 x 1080 pixels |
| Front camera HD type |
Full HD |
| Network |
|---|
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Antenna type |
2x2 |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Bluetooth |
Yes |
| Bluetooth version |
5.4 |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| Combo headphone/mic port |
Yes |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Performance |
|---|
| Repairability index |
9.7 |
| Keyboard |
|---|
| Pointing device |
Touchpad |
| Keyboard backlit |
Yes |
| Numeric keypad |
Yes |
| Keyboard backlit zone |
1-zone RGB |
| Keyboard backlit colour |
RGB |
| Copilot key |
Yes |
| Software |
|---|
| Operating system installed |
Windows 11 Home |
| Operating system architecture |
64-bit |
| Trial software |
1-month trial for new Microsoft 365 customers. Credit card required, McAfee 30 days |
| Bundled software |
Xbox Game Pass for PC_3 months (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass for PC. Eligible markets are determined at activation. Game catalog varies by region, device, and time.) |
| Microsoft Copilot |
Yes |
| Copilot+ PC |
No |
| Battery |
|---|
| Battery technology |
Lithium-Ion (Li-Ion) |
| Number of battery cells |
4 |
| Battery capacity |
70 Wh |
| Fast charging |
Yes |
| Fast charging time (50%) |
30 min |
| Power |
|---|
| AC adapter power |
200 W |
| AC adapter frequency |
50 - 60 Hz |
| AC adapter input voltage |
100 - 240 V |
| AC adapter output current |
10 A |
| AC adapter output voltage |
20 V |
| DC-in jack |
Yes |
| Required charging power (max) |
100 W |
| Required charging power (min) |
45 W |
| USB Type-C charging port |
Yes |
| USB Power Delivery (USB PD) |
Yes |
| Security |
|---|
| Password protection |
Yes |
| Password protection type |
BIOS, User |
| Weight & dimensions |
|---|
| Weight |
2.2 kg |
| Width |
354 mm |
| Depth |
269 mm |
| Height (front) |
1.79 cm |
| Height (rear) |
2.57 cm |
| Packaging content |
|---|
| AC adapter included |
Yes |
