APC Smart-UPS On-Line, 10kVA/10kW, Rackmount 6U, 230V/400V, 4x 32A IEC outlets, Network Card+SmartSlot, Extended runtime, W/ custom PDU, W/ rail kit

APC
€10,986.99
€10,986.99
Tax included.
Out of Stock
  • 10kVA/10kW double-conversion on-line pure sine wave 6U rackmount UPS
  • Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications
  • Rack/Tower convertible (rail kit included)
  • 1-Year Secure Network Management Card subscription included
  • Add up to 10 external battery packs (SRT192RMBP2) for extended runtime
  • Embedded Network Management Card for network-based UPS monitoring & management
  • Graceful shutdown of physical servers, virtual machines and HCI Clusters
  • SmartSlot for additional communication options
  • Delivers clean power with zero transfer time for critical or sensitive devices

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 10kVA on-line 6U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with hard wire 3-wire input and hard wire 3-wire/5-wire output connections and 4x IEC 32A outlets. The UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It has an additional SmartSlot for optional accessory card such as Dry Contact I/O card. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. It conforms to CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, and VDE. Designed for IT professionals or network administrators providing wide input voltage window, tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.

Design
PDU types Basic
Type Three-phase
Mounting Vertical
Product colour Black
Display LCD
On/off switch Yes
Ports & interfaces
AC outlets quantity 10 AC outlet(s)
AC outlet types C13 coupler, C14 coupler
Ethernet LAN (RJ-45) ports 2
USB ports quantity 1
Features
LED indicators Power, Status
Power
Nominal input voltage 230, 400 3PH
AC input frequency 40-70 Hz
Maximum current 47 A
Nominal output voltage 230 V
Output voltage 230 V
Maximum input current per phase 54 A
Maximum total current draw per phase 18 A
Battery replacement accessibility End-user
Surge energy rating 480 J
Surge protection Yes
Maximum power 10000 W
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance Yes
Compliance certificates RoHS, REACH, WEEE
Certification CE; EAC; IRAM; RCM; VDE
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -15 - 45 °C
Storage relative humidity (H-H) 0 - 95%
Operating relative humidity (H-H) 0 - 95%
Operating altitude 0 - 3048 m
Non-operating altitude 0 - 15240 m
Weight & dimensions
Width 432 mm
Depth 715 mm
Height 263 mm
Weight 111.8 kg
Packaging content
Cables included USB
Manual Yes
Rack mount kit Yes
Packaging content CD with software, Documentation CD, Installation guide, Rack mounting brackets, Rack mounting hardware, Rack mounting support rails, Temperature probe, USB cable, Warranty card, Web/SNMP management card
Packaging data
Package weight 130 kg
Package width 600 mm
Package depth 1000 mm
Package height 461 mm
Package type Box
Technical details
Packaging recycled materials Recycled cardboard
Preferred mounting position no preference
Packaging without single use plastic No
Take-back system No
SCIP number 409c68a1-39a6-4e5f-b080-12befe783ad8
Sustainable packaging No
Logistics data
Customs product code (TARIC) 8504409590
Country of origin Philippines
Total carbon footprint (kg of CO2e) 8870.136742139415
